•  Colour inkjet printer
  • ISO Standard print speed (A4): up to 4.0ipm (colour) / 8.0ipm (mono)

Features

Compact Design

PIXMA iP2870

Allow the printer to easily fit into even the smaller spaces and shelves in a home.

Auto Power ON

PIXMA iP2870

Auto Power ON detects a print command and will automatically switch the printer on with a USB connection.

Impressive results at affordable prices

PIXMA iP2870

Choose optional XL ink cartridges - a better value for users who print frequently.




Printer
Maximum Printing Resolution 4800 (horizontal)*1 x 600 (vertical) dpi
Print Head / Ink Type: FINE Cartridge
Number of Nozzles: Total 1,280 nozzles
Ink Droplet Size: 2pl
Ink Tank: PG745, CL-746 (Optional: PG-745XL, CL-746XL)
Print Speed*2
Based on ISO / IEC 24734.
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions		 Document: Col ESAT / Simplex approx. 4.0ipm
Document: B / W ESAT / Simplex approx. 8.0ipm
Printable Width Up to 203.2mm (8inch)
  Bordered Printing Top margin: 3mm, Bottom margin: 16.7mm,
Left / Right margin: each 3.4mm (LTR / LGL: Left: 6.4mm, Right: 6.3mm)
Recommended Printing Area Top margin: 31.6mm / Bottom margin: 29.2mm
Paper Size A4, A5, B5, LTR, LGL, 4 x 6", 5 x 7", Envelopes (DL, COM10), Custom size (width 101.6mm - 215.9mm, length 152.4mm - 676mm)
Paper Handling (Rear Tray)
(Maximum Number)		 Plain Paper A4, A5, B5, LTR=60, LGL=10
Photo Paper Plus Glossy II (PP-201) 4 x 6"=20
Glossy Photo Paper "Everyday Use" (GP-601) 4 x 6"=20
Envelope European DL / US Com. #10=5
Paper Weight Rear Tray Plain Paper: 64-105 g/m2 , Canon specialty paper: max paper weight : approx. 275 g/m2 (Photo Paper Plus Glossy II (PP-201))
Ink End Sensor Dot count
Print Head Alignment Manual
System Requirements
Windows: (Please visit www.canon-asia.com to check OS compatibility and to download the latest driver updates.) Windows 8 / Windows 7 / Windows XP / Windows Vista
Macintosh: Mac OS X v10.6.8 and later
General Specifications
Interface USB 2.0 Hi-Speed
Operating Environment Temperature: 15 -30?C; Humidity: 10 - 80% RH (no dew condensation)
Storage Environment Temperature: 0 - 40?C; Humidity: 5 - 95% RH (no dew condensation)
Power AC 100-240V 50 / 60Hz
Power Consumption Standby (USB connection to PC) Approx. 0.8W
OFF: Approx. 0.5W
Printing *4 Approx. 8.0W
Environment Regulation: RoHS (EU, China), WEEE (EU)
Eco-Label: Energy Star, EPEAT
Dimension (W x D x H)   approx. 426 x 235 x 134mm
Weight   approx. 2.3kg


Specifications are subject to change without notice.

*1

Ink droplets can be placed with a pitch of 1 / 4800 inch at minimum.
*2 Document print speeds are the averages of ESAT in Office Category Test for the default simplex mode, ISO / IEC 24734.
Photo print speed is based on the default setting using ISO / JIS-SCID N2 on Photo Paper Plus Glossy II and does not take into account data processing time on host computer.
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
*3 Paper types NOT supported for borderless printing are as follows: Envelope, High Resolution Paper, T-Shirt Transfer, Photo Stickers.
*4 Print: When printing ISO / JIS-SCID N2 on A4 size plain paper using default settings.
