NEC Storage M300

Disk array suitable for virtualization environments with high performance, high availability and rich solutions.

Compare

User-friendly GUI makes storage management and data handling easy

The highly visual Web browser screens let you quickly grasp the status of each system component, including the storage capacity, disk load, and status of the connected servers. Easy-to-understand navigation windows allow you to make changes to the replication settings or capacity, as well as guide you through fault handling in the event of a failure. The M300 Disk Array GUI can be navigated with confidence, even by first-time users.

Ramp up capacity and performance just by adding hard disk drives

In today's environment of rapid changes, you need a storage solution that responds quicky and flexibly to sudden fluctuations in data volumes. M300 Disk Array offers a newly developed Advanced Dynamic Pool technology that revolutionizes the conventional virtual pool concept. If capacity runs short, you can increase pool capacity simply by adding hard disk drives-M300 Disk Array will automatically organize the data into the optimal configration to raise the performance of the entire data pool.

An advanced power-saving design that slashes power consumption

With M300 Disk Array, NEC has used its state-of-the-art low power technologies to produce a storage device that slashes previous power consumption levels to achieve one of the best power ratings in the industry. M300 Disk Array uses a power-efficient processor and autonomously controls the operating mode to reduce the power consumption of the entire system. Low-power components such as a highly efficient power supply have been used to the greatest extent possible, and unnecessary components have been eliminated to reduce power consumption still further. M300 Disk Array also operates in environments with temperatures of up to 40 degrees Celsius, 104 degrees Fahrenheit reducing air-conditioning energy use.

A data backup system that does not affect online operations

Having to stop your business volume every day to back up data is highly inefficient. M300 Disk Array provides a snapshot function to save only the data sections that have changed (update differences) and a function to completely replicate (copy) an entire data volume without disrupting operations. The replicated volume can then be used for tape backup or batch processing, or to evaluate applications using the actual data.



Specification

Model Name M300 3.5" Drive Model
Chassis Structure Up to 7(seven) 3.5" and 2.5" Disk Enclosures can be connected to the Disk Array Controller under the condition that the number of HDD slots should be up to 144.
HDD slots in a chassis;
Disk Array Controller(3.5"):12
Disk Enclosure(3.5"):12
Disk Enclosure(2.5"):24
Host Interface FC(8Gbps), iSCSI(1Gbps or 10Gbps), SAS(6Gbps)
Number of Host Port FC:8, SAS:8, iSCSI:4,
FCx4+iSCSI(1G)x4
Cache Memory Capacity 8GB or 16GB
Backup method Save to flash memory
RAID level RAID-0, 1, 5, 6, 10, 50, 60, TM
Drives Interface SAS(6Gbps)
Type / Capacity / Rotation Speed SAS HDD 3.5" 300GB,450GB,600GB(15,000rpm)
Nearline SAS HDD 3.5" 1TB,2TB,3TB,4TB(7,200rpm)
SAS SSD 3.5" 100GB,400GB
Encryption SAS HDD 3.5" 600GB(15,000rpm)
Max. Storage Capacity (*1) SAS HDD 44.5TB
Nearline SAS HDD 303.3TB
SAS SSD 27.2TB
Encryption SAS HDD 44.5TB
Number of Drives 3-96(3.5"HDD), 3-144(2.5"HDD)
Support OS (*2) Windows, Linux, VMware, HP-UX, AIX, Solaris
Chassis Dimensions (width x depth x height) Disk Array Controller 482.0 x 513.2 x 87.8 mm (2U, w/o Front Bezel)
482.0 x 545.2 x 87.8 mm (2U, w/ Front Bezel)
Disk Enclosure 482.0 x 513.2 x 87.8 mm (2U, w/o Front Bezel)
482.0 x 545.2 x 87.8 mm (2U, w/ Front Bezel)
Weight Disk Array Controller 31kg or less
Disk Enclosure 29kg or less
Power Requirements AC100 - 240V single phase 50/60Hz
Power Consumption(Max./ @25 deg.C) Disk Array Controller (*3) SAS HDD 510W / 420W
Nearline SAS HDD 455W / 370W
Disk Enclosure SAS HDD 315W / 265W
Nearline SAS HDD 265W / 215W
Temperature Operating: 5 to 40 degrees Celsius (41 to 104 degrees Fahrenheit)
Non-operating: -10 to 60 degrees Celsius (14 to 140 degrees Fahrenheit)
Relative Humidity Operating: 10 to 80%RH
Non-operating: 5 to 80%RH

*1: Calculated on "1GB=1,024^3B","1TB=1,024^4B" basis.

*2: There might be some restrictions on the OS when connected with disk arrays. For more information, please feel free to contact NEC.

*3: Host interface is FC+iSCSI(1Gbps).

Environmental compliance
?Complying with “CIRCULAR, No.30/2011/TT-BCT (Hanoi, August 10 2011), Temporary
regulations on content limit for certain hazardous substances in electrical products”

M300 2.5" Drive Model Specifications.


Model Name M300 2.5" Drive Model
Chassis Structure Up to 7(seven) 3.5" and 2.5" Disk Enclosures can be connected to the Disk Array Controller under the condition that the number of HDD slots should be up to 144.
HDD slots in a chassis;
Disk Array Controller(2.5"):24
Disk Enclosure(2.5"):24
Disk Enclosure(3.5"):12
Host Interface FC(8Gbps), iSCSI(1Gbps or 10Gbps), SAS(6Gbps)
Number of Host Port FC:8, SAS:8, iSCSI:4,
FCx4+iSCSI(1G)x4
Cache Memory Capacity 8GB or 16GB
Backup method Save to flash memory
RAID level RAID-0, 1, 5, 6, 10, 50, 60, TM
Drives Interface SAS(6Gbps)
Type / Capacity / Rotation Speed SAS HDD 2.5" 300GB,450GB,600GB,900GB,1.2TB(10,000rpm), 300GB(15,000rpm)
Nearline SAS HDD 2.5" 1TB(7,200rpm)
SAS SSD 2.5" 100GB,400GB
Encryption SAS HDD 2.5" 600GB(10,000rpm)
Max. Storage Capacity (*1) SAS HDD 135.9TB
Nearline SAS HDD 114.2TB
SAS SSD 40.9TB
Encryption SAS HDD 66.7TB
Number of Drives 3-96(3.5"HDD), 3-144(2.5"HDD)
Support OS (*2) Windows, Linux, VMware, HP-UX, AIX, Solaris
Chassis Dimensions (width x depth x height) Disk Array Controller 482.0 x 513.2 x 87.8 mm (2U, w/o Front Bezel)
482.0 x 545.2 x 87.8 mm (2U, w/ Front Bezel)
Disk Enclosure 482.0 x 513.2 x 87.8 mm (2U, w/o Front Bezel)
482.0 x 545.2 x 87.8 mm (2U, w/ Front Bezel)
Weight Disk Array Controller 31kg or less
Disk Enclosure 29kg or less
Power Requirements AC100 - 240V single phase 50/60Hz
Power Consumption(Max./ @25 deg.C) Disk Array Controller (*3) SAS HDD 505W / 420W
Nearline SAS HDD 470W / 385W
Disk Enclosure SAS HDD 310W / 260W
Nearline SAS HDD 275W / 225W
Temperature Operating: 5 to 40 degrees Celsius (41 to 104 degrees Fahrenheit)
Non-operating: -10 to 60 degrees Celsius (14 to 140 degrees Fahrenheit)
Relative Humidity Operating: 10 to 80%RH
Non-operating: 5 to 80%RH

*1: Calculated on "1GB=1,024^3B","1TB=1,024^4B" basis.

*2: There might be some restrictions on the OS when connected with disk arrays. For more information, please feel free to contact NEC.

*3: Host interface is FC+iSCSI(1Gbps).

Environmental compliance
?Complying with “CIRCULAR, No.30/2011/TT-BCT (Hanoi, August 10 2011), Temporary
regulations on content limit for certain hazardous substances in electrical products”
