PIXMA G3010

Refillable Ink Tank Wireless All-In-One for High Volume Printing

Designed for high volume printing at low running cost

  • Print, Scan & Copy
  • ISO Standard print speed (A4): up to 8.8ipm black / 5.0ipm colour
  • Hi-speed USB 2.0, WiFi, Mopria, Access Point Mode
  • Recommended print volume: 150 - 1500 pages

Features

High Page Yield Ink Bottles

With high page yield ink bottles up to 7000 pages, users can enjoy printing without having to worry about cost of ink, or ink supplies running low.

Integrated Ink Tank System

Built-in integrated ink tanks create a compact printer body. Users can also view remaining ink levels easily at a glance.

Spill-Resistant Ink Bottle Design

The ink bottles come with a special tip design that reduces spillage during ink refilling.

One-Touch Direct Wireless Connection

Connect to your smartphone easily.

Support Borderless Printing

Print borderless photos up to A4 size

Message in Print App

New ways to express yourself in photos!. Embed secret animated greetings or video and web links, and send to your family and friends. Just download the app* and place your device above the photo to unlock the secret messages.
[*Only available on iOS]


Printer
Maximum Printing Resolution 4800 (horizontal)*1 x 1200 (vertical) dpi
Print Head / Ink Number of Nozzles: Total 1,472 nozzles
Ink Bottles GI-790 (Black, Cyan, Magenta, Yellow)
Print Speed*2
Based on ISO / IEC 24734
Click here summary report
Click here for Document Print and Copy Speed Measurement Conditions		 Document: Col ESAT / Simplex Approx. 5.0ipm
Document: B / W ESAT / Simplex Approx. 8.8ipm
Document: Col FPOT Ready/Simplex Approx. 17secs.
Document: B / W FPOT Ready/Simplex Approx. 11secs.
Document: Col FPOT Sleep/Simplex Approx. 22secs.
Document: B / W FPOT Sleep/Simplex Approx. 14secs.
Photo (4 x 6") PP-201 / Borderless Approx. 60secs.
Printable Width Bordered: Up to 203.2mm (8 inch)
Borderless: Up to 216mm (8.5 inch)
Printable Area Borderless Printing*3 Top / Bottom / Right / Left margin: each 0mm (Supported Paper Size: A4 / Letter / 4 x 6" / 5 x 7" / 8 x 10" / Square (5 x 5") / Business Card)
Bordered Printing Top margin: 3mm,
Bottom margin: 5mm,
Left / Right margin: each 3.4mm
(Letter / Legal: Left: 6.4mm, Right: 6.3mm)
Recommended Printing Area Top margin: 31.2mm
Bottom margin: 32.5mm
Paper Size A4, A5, B5, Letter, Legal, 4 x 6", 5 x 7", 8x 10", Envelopes (DL, COM10), Square (5 x 5"), Business Card, Custom size (width 55 - 215.9mm, length 89 - 676mm)
Paper Handling (Rear Tray)
(Maximum Number)		 Plain Paper A4, A5, B5, Letter = 100, Legal = 10
High Resolution Paper (HR-101N) A4, Letter = 80
Photo Paper Plus Glossy II (PP-201) A4, Letter = 10, 4 x 6" = 20, 5 x 7", 8 x 10" = 10, Square (5 x 5") = 20
Photo Paper Plus Semi-Gloss (SG-201) A4, Letter = 10, 4 x 6" = 20, 5 x 7", 8 x 10" = 10
Matte Photo Paper (MP-101) A4, Letter = 10, 4 x 6" = 20
Envelope European DL / US Com. #10 = 10
Glossy Photo Paper "Everyday Use" (GP-508) A4 = 10, 4 x 6" = 20
Photo Paper Plus Glossy II (PP-208) A4, 4 x 6" = 10
Photo Sticker PS-108, PS-308R, PS-208, PS-808 = 1
Paper Weight Rear Tray Plain Paper: 64 - 105g/m2, Canon specialty paper: max paper weight: approx. 275g/m2 Photo Paper Plus Glossy II (PP-201)
Ink End Sensor Dot count
Print Head Alignment Manual
Scan*4
Scanner Type Flatbed
Scanning Method CIS (Contact Image Sensor)
Optical Resolution*5 600 x 1200dpi
Scanning Bit Depth (Input / Output) Grayscale: 16 / 8-bit
Colour: 48 / 24-bit (RGB each 16 / 8-bit)
Line Scanning Speed*6 Grayscale: 1.5ms/line (300dpi)
Colour: 3.5ms/line (300dpi)
Scanning Speed*7 Reflective:
A4 Colour / 300dpi		 Approx. 19secs.
Maximum Document Size Flatbed: A4 / Letter (216 x 297mm)
Copy
Maximum Document Size A4 / Letter (216 x 297mm)
Compatible Media Size: A4, Letter
Type: Plain Paper
Image Quality Plain Paper: Fast, Standard
Copy Speed*8
Based on ISO / IEC 24734.
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions		 Document: Colour
sFCOT / Simplex		 Approx. 24secs.
Document: Colour
sESAT / Simplex		 Approx. 3.5ipm
Multiple Copy Black / Colour: 1 - 20 pages
Network
Protocol TCP / IP
Wireless LAN Network Type: IEEE 802.11n / IEEE 802.11g / IEEE 802.11b
Frequency Band: 2.4GHz
Channel*9: 1 - 13
Range: Indoor 50m (depends on the transmission speed and conditions)
Security: WEP 64 / 128-bit, WPA-PSK (TKIP / AES), WPA2-PSK (TKIP / AES)
Direct Connection (Wireless LAN) Available (AP Mode only)
Printing Solutions
Mopria Available
Google Cloud Print Available
Smart Device Print Plug-In
(for Android / Amazon device)		 Available
PIXMA Cloud Link From smartphone or tablet: Available
Canon PRINT Inkjet / SELPHY App
(for iOS / for Android)
Canon Easy-PhotoPrint
(for Windows RT)		 Available
Layout 1-up (bordered / borderless*10) Letter, A4, 4 x 6", 5 x 7", 8 x 10", Square 5 x 5", Business card
1-up (bordered only) A5, B5, Legal
Print Quality Fixed
System Requirements
(Please visit www.canon-asia.com to check OS compatibility and to download the latest driver updates)		 Windows: Windows 10, Windows 8.1, Windows 7 SP1
Macintosh: Mac OS is not supported
General Specifications
Operation Panel Display LCD (1.2 inch segment mono)
Interface USB 2.0 Hi-Speed
Paper Output Tray A4, Letter = 50, Legal = 10
Operating Environment*11 Temperature: 5 - 35?C
Humidity: 10 - 90% RH (no dew condensation)
Recommended Environment*12 Temperature: 15 - 30?C
Humidity: 10 - 80% RH (no dew condensation)
Storage Environment Temperature: 0 - 40?C
Humidity: 5 - 95% RH (no dew condensation)
Quiet Mode Available
Acoustic Noise (PC Print)*13 Plain Paper (A4, B/W) Approx. 53.5dB(A)
Power AC 100 - 240V; 50 / 60Hz
Power Consumption Connection to PC WiFi
OFF: Approx. 0.2W
Standby (scanning lamp is off):
(USB connection to PC)		 Approx. 1.2W
Standby (all ports connected, scanning lamp is off) Approx. 1.2W
Copying*14: G3010 Approx. 11W
Typical Electricity Consumption (TEC)*15

0.1kWh
Environment Regulation: RoHS (EU, China)*, WEEE (EU)*
*To be fixed
Eco-Label: Energy Star*
*To be fixed
Dimension (W x D x H) Factory configuration Approx. 445 x 330 x 163mm
Output / ADF trays extended Approx. 445 x 533 x 260mm
Weight

Approx. 6.3kg


Specifications are subject to change without notice.

*1 Ink droplets can be placed with a pitch of 1/4800 inch at minimum.
*2 Document print speeds are the averages of ESAT in Office Category Test for the default simplex mode, ISO / IEC 24734.
Photo print speed is based on the default setting using ISO / JIS-SCID N2 on Photo Paper Plus Glossy II and does not take into account data processing time on host computer.
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
*3 Paper types NOT supported for borderless printing are as follows: Envelope, High Resolution Paper, T-Shirt Transfer, Photo Stickers.
*4 TWAIN driver (ScanGear) is based on the TWAIN specification V1.9 and requires the Data Source Manager comes with the operating system.
*5 Optical resolution is a measure of maximum hardware sampling resolution, based on ISO 14473 standard.
*6 The fastest speed in Hi-Speed USB on Windows PC. Transfer time to computer is not included.
*7 Colour document scan speed is measured with ISO / IEC 29735 Target A.
Scan speed indicates the time measured between pressing the scan button of the scanner driver and the on-screen status display turns off.
Scan speed may vary depending on system configuration, interface, software, scan mode settings and document size etc.
*8 Copy speeds are the average of sFCOT and sESAT, ISO / IEC 29183.
Copy speed may vary depending on document complexity, copy mode, page coverage, type of paper used etc. and does not take into account warm up time.
*9 1-11 in US, CND, LTN, BRA, TW and HK.
*10 The amount of image extension beyond the paper cannot be adjusted.
*11 The performance of the printer may be reduced under certain temperature and humidity conditions.
*12 For the temperature and humidity conditions of papers such as photo paper, refer to the paper's packaging or the supplied instructions.
*13 Acoustic Noise is measured based on ISO 7779 standard.
*14 Copy:When copying ISO / JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings.
*15 Typical Electricity Consumption (TEC) value: TEC value was calculated assuming the unit will be constantly switched among operational mode, sleep mode, and power-off mode for 5 days, and that it will be either in sleep or power-off mode for the remaining 2 days within the same week. The TEC value of this product is calculated by Canon on their own accord using TEC measurement procedure regulated in International ENERGY STAR Program.


Disclaimer

? You need to install ink bottles of all colours whether you perform black and white printing or colour printing. If any of the ink bottles is not installed, an error occurs and you cannot perform printing.
? Even when black-only or grayscale printing is selected, depending on the printing material and driver settings used, colour inks might still be consumed when printing. When the remaining ink level of any ink tank falls below the lower limit line, Canon recommends that you refill that ink bottle with the corresponding colour of ink.
? During the initial printer setup, a certain amount of ink is used to fill the print head's nozzles with ink. Therefore, the page yield of the initial bundled set of ink bottles will be lower than that of the subsequent sets of bottles.
? To keep printer's performance, Canon printer performs cleaning automatically according to its condition. When the printer performs cleaning, a small amount of ink is consumed.
In this case, all colours of ink may be consumed.
[Cleaning function]
The cleaning function helps the printer to suck air bubbles or ink itself from the nozzle and thus prevents print quality degradation or nozzle clogging.
? The repairing parts for printers will be available five years after production is discontinued. Depending on your model, we may ask you to replace it with a new one, or one with almost the same performance as a maintenance service. In this case, it may be that you cannot use supplies or accessories for your model or the compatible OS will be changed.
? The warranty term for details, contact a Canon-authorized sales representative in the country or region you live in. The warranty covers only the printer main body excluding consumables such as print media and ink / ink bottles even during the warranty period.
? To obtain good printing quality, use up ink within six months after opening.
? Please take note that if the printer fault or breakdown is due to the usage of non-genuine inks, repair charges are applicable even if the claim is within the warranty period.
? Using non-genuine inks may affect the printer's performance and / or the print quality. In some rare occasions, although there are no safety issues, using non-genuine inks has caused overheating of the print head and smoke emission from the print head due to the absence of an ingredient found in genuine ink. (Does not apply to usage of all non-genuine inks).
? Depending on your terminal, such as a computer or a smartphone, or the operating system of your terminal, such as your computer or smartphone, the estimated ink level information or message displayed on the screen of your terminal may be different from the information or message displayed on the operation panel of the printer. Also, a part of the estimated ink level message displayed on the operation panel of the printer may not be displayed and / or may be displayed at a different point in time. Canon recommends that you use the information and message displayed on the operation panel of the printer as your reference. Note, however, that such information and message are displayed items serve only as a guideline information.
