Machine Type

A3 Colour Laser Multifunctional

Core Functions

Print, Copy, Scan, Send, Store and Optional Fax

Processor

Canon Dual Customer Processor (Shared)

Control Panel

Standard: 10.1" TFT LCD WSVGA Color Touch panel
Optional: 10.4" TFT LCD SVGA Color Upright Touch Panel

Memory

Standard: 4.0GB RAM

Hard Disk Drive

Standard*1: 320 GB(available disk space: 250 GB)
Optional: 250GB, 1TB

Mirroring Hard Disk Drive

Optional

Interface Connection

NETWORK
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)
Optional: NFC, Bluetooth Low Energy

OTHERS
Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1
Optional: Serial Interface, Copy Control Interface

Paper Supply Capacity (A4, 80 gsm)

Standard: 3,550 sheets
250-sheet Multi-purpose tray x 1,
1,100-sheet Paper Deck x 2,
550-sheet Paper Cassette x 2

Maximum: 9,300 sheets(with Multi-Drawer Paper Deck-C1)

Paper Output Capacity (A4, 80 gsm)

250 sheets (with Copy Tray-R2)
Maximum: 4,250 Sheets (with Staple Finisher-X1 or Booklet Finisher-X1)

Finishing Capabilities

With options: Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand, Document Insertion, Z-fold, Half-fold, C-fold, Accordion-Z fold, Double Parallel-fold, Trimming

Supported Media Types

Multi-purpose tray:
Thin, Plain, Recycled, Colour, Heavy, Coated, Textured, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab, Envelope

Paper Decks (Right/Left):
Thin, Plain, Recycled, Colour, Heavy, Tracing, Bond, Transparency, Bond, Pre-punched, Letterhead

Paper Cassettes (Upper/Lower):
Thin, Plain, Recycled, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead, Tab*2, Envelope*3

Supported Media Sizes

Multi-purpose tray:
Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom size: 100.0 x 148.0 mm to 330.2 x 487.7 mm
Free size: 100.0 x 148.0 mm to 330.2 x 487.7 mm
Envelope: COM10 No.10, Monarch, DL, ISO-C5
Envelope custom size: 90.0 x 148 mm to 330.2 x 487.7 mm

Paper Decks (Right/Left):
Standard size: A4, B5

Paper Cassettes (Upper/ Lower):
Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
Custom size: 139.7 x 182.0 mm to 330.2 x 487.7 mm
Envelope: COM10 No.10, Monarch, DL, ISO-C5
Envelope custom size: 98.0 x 148.0 mm to 330.2 x 487.7 mm

Supported Media Weights

Multi-purpose tray: 52 to 300 gsm
Paper Deck (Right/Left): 52 to 220 gsm
Paper Cassette (Upper/Lower): 52 to 256 gsm
Duplex: 52 to 220 gsm

Warm-up Time

Quick startup mode: 4 seconds or less*4
From Sleep Mode: 30 seconds or less
From Power On: 30 seconds or less*5

Dimensions (W x D x H)

689 x 937 x 1,185 mm

Installation Space (W x D)

Basic:
2,026 x 1,524 mm (with Front door open + Multi-purpose tray/upper-right cover open + Buffer Pass-M1 + Booklet Finisher-AC1/extension tray & rotary tray extended )

Fully Configured:
3,818 x 1,524 mm (with Multi-Drawer Paper Deck-C1 + Buffer Pass-M1 + Document Insertion Unit-N1 + Multi Function Professional Puncher-B1 + Paper Folding Unit-J1 + Booklet Finisher-X1/extension tray extended )

Weight

Approx. 257 kg (including toner)

Print Speed (BW/CL)

iR-ADV DX C7780i:
Up to 80/70 ppm (A4, A5*6, A5R, A6R*6), Up to 40/35 ppm (A3), Up to 56/49 ppm (A4R)

Print Resolution (dpi)

2,400 x 2,400

Page Description Languages

Standard: UFR II, PCL6
Optional: Adobe? PostScript?3?

Direct Print

Supported file types: PDF, EPS, TIFF/JPEG, and XPS

Printing from Mobile and Cloud

AirPrint, Mopria, Google Cloud Print, Canon Business Print and uniFLOW Online

A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements.
Please contact your sales representative for further information

Fonts

PS fonts: 136 Roman
PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andal? Mono WT J/K/S/T*7 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*8

Print Features

Secured Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/ Orientations, Front/Back Covers, Toner Reduction, Poster Printing, Forced hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer

Operating System

UFRII: Windows? 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019, Mac OS X (10.10 or later)

PCL: Windows ?7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019
PS: Windows? 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server2016 / Server2019, Mac OS X (10.10 or later)

PPD: Windows? 7 / 8.1 / 10, Mac OS X (10.9 or later)

As of July, 2019.

Copy Speed (BW/CL)

iR-ADV DX C7780i:
Up to 80/70 ppm (A4, A5*9, A5R, A6R*9), Up to 40/35 ppm (A3), Up to 56/49 ppm (A4R)

First-Copy-Out Time (A4, BW/CL)

iR-ADV DX C7780i: Approx. 4.4/5.4 seconds or less

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 9,999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

Variable zoom: 25% to 400% (1% Increments)
Preset reduction/enlargement: 25%, 50%, 61%, 70%, 81%, 86%, 100% (1:1), 115%, 122%, 141%, 200%, 400%

Copy Features

Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Job Build, N on 1, Add Cover, Insert Sheets, Different Size Originals, Page Numbering, Copy Set Numbering, Sharpness, Erase Frame, Secure Watermark, Print Date, Gutter, Print & Check, Negative/Positive, Repeat Images, Merge Job Blocks, Mirror Image, Store in Mail Box, Superimpose Image, Copy ID Card, Skip Blank Pages, Free Size Original, Colour Mode, Reserved copy, Copy Sample

Type

Single-pass Duplexing Automatic Document Feeder*10 [2-sided to 2-sided (Automatic)]

Document Feeder Paper Capacity (80 gsm)

Up to 200 Sheets

Acceptable Originals and Weights

Platen:
Sheet, Book and 3-Dimensional Objects

Document Feeder media weight:
1-sided scanning: 38 to 220 gsm (BW, CL)
2-sided scanning: 38 to 220 gsm (BW, CL)

An acceptable weights of A6R or smaller is 50 to 220gsm.

Supported Media Sizes

Platen max. scanning size: up to 297.0 x 431.8 mm

Document Feeder media size:
A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, B6R,
Custom size: 70.0 x 139.7 mm to 304.8 x 431.8 mm

Scan Speed (ipm: BW/CL, A4)

1-sided Scanning:
135/135 (300 x 300 dpi, send), 80/80 (600 x 600 dpi, copy),

2-sided Scanning:
270/270 (300 x 300 dpi, send), 160/90 (600 x 600 dpi, copy)

Scan Resolution (dpi)

Scan for Copy: 600 x 600
Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600
Scan for Fax: 600 x 600

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows? 7 / 8.1 / 10 / Server2008 / Server2008 R2 / Server2012 / Server2012 R2 / Server 2016

Scan Method

Push Scan, Pull Scan, Scan to Box, Scan to Advanced Box, Scan to Network, Scan to USB Memory Key, Scan to Mobile device, Scan to cloud (uniFLOW Online)

Destination

Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV, Mail Box
Optional: Super G3 FAX, IP Fax

Address Book

LDAP (2,000)/Local (1,600)/Speed dial (200)

Send Resolution (dpi)

Push: up to 600 x 600
Pull: up to 600 x 600

Communication Protocol

File: FTP (TCP/IP), SMB3.0 (TCP/IP), WebDAV
E-mail/I-Fax: SMTP, POP3

File Format

Standard: TIFF, JPEG, PDF (Limited Colour, Compact, Searchable, Apply policy, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

Universal Send Features

Original Type Selection,Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Copy Ratio, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Pages

Maximum Number of Connection Lines

4

Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

400x400 (Ultra Fine), 200x400 (Super Fine), 200x200 (Fine), 200x100 (Normal)

Sending/Receiving Size

Sending: A3, A4, A4R, A5*11, A5R*11, B4, B5*12, B5R*11
Receiving: A3, A4, A4R, A5R, B4, B5, B5R

FAX Memory

Up to 30,000 pages (2,000 jobs)

Speed Dials

Max. 200

Group Dials / Destinations

Max. 199 dials

Sequential Broadcast

Max. 256 addresses

Memory Backup

Yes

Fax Features

Sender's Name (TTI), Selecting the Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox, 2 on 1 Log

Mail Box (Number supported)

100 User Inboxes
1 Memory RX Inbox
50 Confidential Fax Inboxes

Maximum 10,000 Pages (2,000 jobs) Stored

Advanced Box

Communication Protocol: SMB or WebDAV
Supported Client PC: Windows? 8.1/10
Concurrent Connections (Max.): SMB:64, WebDAV:3

Advanced Box Available Disc Space

Standard:16 GB
(With option: max. 480GB)

Advanced Box Features

Authentication for Advanced Box Log-in, Sort Function, Printing a PDF File with a Password, imageWARE Secure Audit Manager Support, Search, File Preview, Authentication Management, Open to public, URI TX, Backup/Restore

Authentication and Access Control

Standard:User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online Express (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Access Management System (Access Control)

Document Security

Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print*13), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle? Rights Management ES2.5 Integration), BOX Security (Mail Box Password Protected, Advanced Box Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark)

Network Security

TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Disabling Unused Functions (Enabling/Disabling Protocols/Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Box in the MFP, Scan and Send -Virus Concerns for E-mail Reception

Device Security

Protecting HDD Data (HDD Data Encryption (FIPS140-2 Validated), HDD Data Overwrite Erase, HDD Lock), Standard HDD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Protecting MFD Software Integrity, Checking MFD Software Integrity (Verify System at Startup, Runtime Intrusion Detection)
Optional: IEEE2600.2 (Common Criteria Certification) (TBD)

Device Management and Auditing

Administrator Password, Digital Certificate And Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Operating Environment

Temperature: 10 to 30 ?C
Humidity: 20 to 80 % RH (Relative Humidity)

Power Source

iR-ADV DX C7780i: 220-240V 50/60Hz 11A
iR-ADV DX C7770i: 220-240V 50/60Hz 10A

Power Requirements

220-240V, 50/60Hz, 4A

Power Consumption

Maximum: Approx. iR-ADV DX C7780i: 2,500 W, iR-ADV DX C7770i: 2,000 W
Standby: Approx. 119.6 W*14
Sleep mode: Approx. 0.9 W*15

Toner Cartridges

NPG-72 Toner BK/C/M/Y

Toner (Estimated Yield @ 5% Coverage)

NPG-72 Toner BK: 82,000 pages
NPG-72 Toner C/M/Y: 66,500 pages

Tracking and reporting

Universal Login Manager (ULM)
uniFLOW Online Express

Remote Management Tools

iW Management Console
eMaintenance
Content Delivery System

Scanning Software

Network ScanGear

Optimisation Tools

Canon Driver Configuration Tool
NetSpot Device Installer

Platform

MEAP (Multifunctional Embedded Application Platform)

Document Publishing

IW DESKTOP

Optional/Standard

Optional

Name

imagePASS-N2 V1.1 (Embedded)

Print Resolution (dpi)

1200 x 1200, 600 x 600

Page Description Language(s)

PCL6, Adobe? PostScript?3?

Memory

4GB (1 x 4GB)

Hard Disk Drive

500 GB SATA

Processor Speed

Intel Pentium G4400 (3.3GHz)

System

FS350

Fonts

PS: 138 Fonts
PCL: 113 Fonts

Supported Operating Systems

Windows? 7 64 bit/Windows? 8.1 64 bit/Windows? 10 64 bit/Windows? Server 2008 R2 64bit only/Windows? Server 2012 64bit only (Only Printer driver support)/Windows? Server 2012 R2 64bit only/Windows? Server 2016 R2 64 bit only, MAC OS (10.11,10.12, 10.13, 10.14)

Interface

2 x Ethernet (1000Base-T/100Base-TX/10Base-T), USB 3.0 x 2 (rear), x 3 (front on Fiery Quick Touch TM), USB 2.0 x 4 (rear)

Network Protocols

TCP/IP (FTP, SMTP, POP, HTTP, SNMP, LDAP, SLP, SMB, LPD, IPP, WS-Discovery, Bonjour, Direct Mobile Printing, Port9100, SNTP, 802.1X, DHCP, DNS, NTP)

Direct Print

PDF1.7, EPS, TIFF6, JDF1.4/JMF (Optional)

VDP

FreeForm v1, v2.1

Fiery Print Controller Standard Features

Fiery Command WorkStation 6 / Paper Catalog / Fiery Spot-On / Fiery Remote Scan / Fiery Hot Folders & Virtual Printers

Fiery Print Controller Options

Fiery Impose / Fiery Compose / Fiery Impose and Compose / Productivity Package Web Activate (Include Fiery JDF)

HW Platform

E400

Base OS

Debian of Linux

Power Source

AC100-240V, 50Hz/60Hz, 3.0A (100V) - 1.3A (240V)

Maximum Power Consumption

47 W

Dimensions (W x D x H)

285 x 93 x 295 mm

Weight

Fiery unit only (with plate): Approx. 5 kg

Paper Deck Unit-E1

Paper Capacity: 3,500 sheets (80 gsm)
Paper Type: Thin, Plain, Recycled, Colour, Heavy, Bond, Pre-punched, Letterhead
Paper Size: A4, B5
Paper Weight: 52 to 256 gsm
Power Source: from the Main Unit
Dimensions (W x D x H): 340 x 630 x 572 mm (attached to the main unit)
Weight: Approx. 34 kg

POD Deck Lite-C1

Paper Capacity: 3,500 sheets (80 gsm)
Paper Type: Thin, Plain, Recycled, Colour, Heavy, Coated, Textured, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab, Envelope*16
Paper Size: SRA3, A3, B4, A4, A4R, A5R, B5, B5R, Envelope (COM10 No10, Monarch, DL, ISO-C5)
Custom size: 139.7 x 148.0 mm to 330.2 to 487.7 mm
Paper Weight: 52 to 300 gsm
Power Source: 220-240V/1.2A?50/60Hz
Dimensions (W x D x H): 633 x 686 x 574 mm (attached to the main unit)
Weight: Approx. 68 kg

Multi-drawer Paper Deck-C1

Paper Capacity: 2,000 sheets x3, total 6,000 sheets (80 gsm)
Paper Type: Thin, Plain, Heavy, Recycled, Colour, Pre-punched, Transparency, Label, Coated, Textured, Tab, Bond, Letterhead
Paper Size: SRA3, A3, A4, A4R, A5R, B4, B5, B5R
Custom size: 139.7 x 182.0 mm to 330.2 to 487.7 mm
Paper Weight: 52 to 300 gsm
Power Source: 220-240V, 50/60Hz, 1.7A
Dimensions (W x D x H): 950 x 797 x 1,040 mm (attached to the main unit)
Weight: Approx. 155 kg

Card Readers

Copy Card Reader-F1
Copy Card Reader Attachment-A4

Others

Utility Tray-B1
Printer Cover-H2
Tab Feeding Attachment-F1
Upright Control Panel-J1
Numeric Keypad-A1
Finisher Jogger Kit-A1
Envelope Feeder Attachment-F1
Envelope Feeder Attachment-G1

Device Security

iR-ADV Security Kit-AH1 for IEEE 2600 Common Criteria Certification (TBD)

Data Security

HDD Mirroring Kit-J1
2.5inch/250GB HDD-N1
2.5inch/1TB HDD-P1

Print Accessories

PCL International Font Set-A1
PCL Asian Font Set-A1

Barcode Printing

Barcode Printing Kit-D1

EFI-Fiery Based Controller (Embedded)

imagePASS-N2 V1.1

EFI-Fiery Based Controller Options (Embedded)

Fiery Impose
Fiery Compose
Fiery Impose and Compose

System Accessories

Copy Control Interface Kit-A1
Connection Kit-A2 for Bluetooth LE
Serial Interface Kit-K3
NFC Kit-E1

FAX Accessories

Super G3 FAX Board-AS1
Super G3 2nd Line Fax Board-AS1
Super G3 3rd/4th Line Fax Board-AS1
Remote Fax Kit-A1
IP FAX Expansion Kit-B1

Accessibility Accessories

ADF Access Handle-A1
Voice Guidance Kit-G1
Voice Operation Kit-D1

Staple Cartridge

Staple-N1
Staple-P1
Staple Cartridge-X1
Staple Cartridge-Y1
